| Body Construction/Dimensions | |
| Tank material | Poly (3/8") |
| Chassis construction | 3/16" steel |
| Front wheels | (2x) 9" x 3" |
| Rear casters | (2x) 4" x 2" |
| Size (L x W x H) | 45" x 18" x 40" |
| Weight (without batteries) | 152 lb |
| Weight (with batteries) | 387 lb |
| Scrubdeck System | |
| Disk size | 20" |
| Scrubdeck down pressure | 0-150 lb |
| Solution down pressure | 0-150 lb |
| Solution System | |
| Solution tank capacity | 17 gal |
| Solution flow rate | 0 - 1.0 gpm |
| Solution filter | Stainless / Inline |
| Recovery System | |
| Recovery Tank Capacity | 17 gal |
| Vacuum power | 0.75 hp |
| Drain hose | 1.5" diameter |
| Vacuum specs (lift / airflow) | 70" / 70 cfm |
| Demisting chamber | 1.25 gal |
| Drain saver | 30 in |
| Drive System | |
| Standard drive | 0.75 hp (559 watts), all gear/sealed |
| Forward speed | 0-230 ft/min (4 mph) |
| Reverse speed | 0-130 ft/min (2 mph) |
| Productivity | |
| Scrubbing width | 24" |
| Scrubbing rate/hour | 25,543 ft/hr |
